Overview

Product Main Dimensions

Product Specification：QT05-1

Model meaning: QT - electric actuator type 5 - output torque 50NM 1 - output speed 1r/min

Operating stroke: 90°±5°

Protection level IP67

Output torque: 50Nm

Motor power supply: 110/220V AC 1PH 380/440V AC 3PH 50/60HZ Special power requirements need to be communicated in advance!

Environmental temperature: -30℃～+70℃ -30℃～+150℃ Special temperature requirements must be confirmed before ordering!

Product Main Dimensions

QT配件图
Parts and material
NO.	Spare Part
1	Shell
2	Limit switch
3	Torque switch
4	Worm Wheel
5	Motor
6	Terminal connection & wiring block
7	Dryer
8	Manual mechanism

QT1～QT4 including QT4X (380V three-phase motor)
Model	Product Model	Output Torque NM	Output RPM R/Min	Motor parameters (three-phase, 380V, 50Hz)		90° Running Time (S)	Reference weight (Kg)
Model	Product Model	Output Torque NM	Output RPM R/Min	Reference power (KW)	Nominal Current A	90° Running Time (S)	Reference weight (Kg)
QT1	QT5-1	50	1	0.025	0.45	15	9
QT1	QT10-1	100	1	0.025	0.45	15	10
QT2	QT15-1	150	1	0.04	0.9	15	12
QT2	QT20-1	200	1	0.04	0.9	15	13
QT3	QT30-0.5	300	0.5	0.06	1	30	17
	QT30-1	300	1	0.06	1	15	17
	QT50-0.5	500	0.5	0.09	1.2	30	18
	QT50-1	500	1	0.09	1.2	15	18
QT4	QT60-0.5	600	0.5	0.2	1.4	30	22
	QT60-1	600	1	0.2	1.4	15	22
	QT80-0.5	800	0.5	0.2	1.4	30	25
	QT80-1	800	1	0.2	1.4	15	25
	QT100-0.5	1000	0.5	0.2	1.4	30	25
QT4X	QT200-0.3	2000	0.3	0.2	1.4	45	38
QT4X	QT250-0.3	2500	0.3	0.2	1.4	45	51

QT1～QT4including QT4X (220V single-phase motor)
Model	Specifications	Output Torque NM	Output RPM R/Min	Motor parameters (Single-phase, 220V, 50Hz)		90° Running Time (S)	Reference weight (Kg)
Model	Specifications	Output Torque NM	Output RPM R/Min	Reference power (KW)	Nominal Current A	90° Running Time (S)	Reference weight (Kg)
QT1	QT04-0.9	40	0.9	0.025	0.45	17.5	6
	QT06-0.9	60	0.9	0.025	0.45		9
	QT09-0.9	90	0.9	0.025	0.45		10
QT2	QT15-0.7	150	0.7	0.04	0.9	20.6	12
QT2	QT19-0.7	190	0.7	0.04	0.9	20.6	13
QT3	QT28-0.6	280	0.6	0.06	1	26.3	17
	QT28-0.6	380	0.6	0.06	1		18
	QT50-0.6	500	0.6	0.09	1		19
QT4	QT60-0.5	600	0.5	0.2	1.2	29.3	22
	QT80-0.5	800	0.5	0.2	1.4		23
	QT100-0.5	1000	0.5	0.2	1.4		25
QT4X	QT200-0.2	2000	0.2	0.2	1.4	80	38
QT4X	QT250-0.2	2500	0.17	0.2	1.4	90	51

Electric actuator QT1-QT4(QT4X) external dimension table
Model	A1	A2	A3	B	B1	φD	φD1	H1	H2	H3	L	L1	L2	N	M
QT1	44	17	336	75	68	102	170	60	256	109	179	62	／	／	／
QT2	49.5	22.5	30	85	77.5	200	200	64	263	113	187	85	76	／	／
QT3	60	33	35	100	77	250	220	70	298	119	202	88	76	125	φ216
QT4(QT4X)	70	43	38	115	87	250	260	78	342	127	225	106	76	135	φ258

RA type (national standard) flange size table
Model	Flange No.	φd1	φd3	φd7		φd8	T	T1	φd	n-d4Deep
Model	Flange No.	φd1	φd3	Reserve Size	maximum allowable	φd8	T	T1	φd	n-d4Deep
QT1	F05	65	50	8	22	38	40	43	102	4-M6 deep12
QT1	F07	90	70	8	22	38	40	43	102	4-M8 deep14
QT2	F07	90	70	10	25	45	45	49	125	4-M8 deep15
QT2	F10	125	102	10	25	45	45	49	125	4-M10 deep18
QT3	F10	125	102	15	35	56	50	53	145	4-M10 deep18
QT3	F12	150	125	15	35	56	50	53	145	4-M12 deep20
QT4	F12	150	125	15	42	65	58	62	175	4-M12 deep20
QT4	F14	175	140	15	42	65	58	62	175	4-M16 deep24
QT4X	F14	175	140	20	52	82	62	72	／	4-M16 deep26
QT4X	F16	210	165	20	52	82	62	72	／	4-M20 deep32

RB Type (System) Flange Size Chart
Model	Valve Size	φd1	φd3	φd7			b	L	φd8	φd	T	T1	n-d4Deep
				Standars Size	Reserve Size	maximum allowable
QT1	2"	77	57.15	12.6	8	22	33	14	38	102	40	43	4-M6 deep12
	2.5"
	3"
QT2	4"	92	69.85	15.7718.92	10	25	5	18.07 21.22	45	125	45	49	4-M10 deep18
	5"
	6"
QT3	8"	115	88.9	22.1	15	35	5	24.4	56	145	50	53	4-M12 deep20
	10"			28.45				31.75
QT4	12"	140	107.95	31.6	15	42	8	24.9	65	175	58	62	4-M12 deep20
	14"
QT4X	18"	197	158.75	38	20	52	10	41.3	82	／	62	72	4-M18 deep26
	20"			41.15				44.45
